ARRI ALEXA 35

Released: June 2022
Sensor: Super 35mm (27.99 x 19.22 mm)
Lens Mount: LPL, PL, EF, M
Base Sensitivity: ISO 800
Weight: 2900 g
Dimensions: 203 mm x 147 mm x 153 mm
COMPARE WITH CAMERA
chevron_right
chevron_right
Check Rec Modes & TimesCheck Lens Coverage
COMPARE WITH CAMERA
chevron_right
chevron_right
Advertisement
Advertisement
Advertisement
Dynamic Range
1st best - max. 15.3 (SNR=2)Check Ranking
1st best - max. 16.3 (SNR=1)Check Ranking
Stops (SNR=2)Stops (SNR=1)WaveformIMATESTPatch RangeCodecISOFramerateResolutionGammaComment
15.116.316.5ARRIRAW800254608x3164LogC4
15.316.116.1ProRes 4444 XQ800254608x3164LogC4
14.91616.7ARRIRAW3200254608x3164LogC4
See Lab Test Article ...
Rolling Shutter
4th best - min. 5.7 msCheck Ranking
Rolling ShutterImageSensor ModeCodecFramerateResolutionComment
7.9 msOpen GateARRIRAW254608x3164
5.7 ms4.6K 16:9ARRIRAW254608x2592
7.6 ms4K 16:9ARRIRAW244096x230424-120p
7.1 msFull SensorH.265 LongGOP1004096x2160
See Lab Test Article ...
Recording Modes Overview
2K (2048 x 1152) @ max 120p, ProRes (XQ)2K (2048 x 1152) @ max 120p, ProRes (XQ)2K (2048 x 1152) @ max 120p, ProRes (HQ)
4K (4096 x 2048 @ max 120p, ProRes (XQ)HD (1920 x 1080) @ max 120p, ProRes4K (4096 x 2048 @ max 120p, ProRes
4K (4096 x 2048 @ max 120p, ProRes (HQ)4K UHD (3840 x 2160) @ max 120p, ARRIRAWHD (1920 x 1080) @ max 120p, ProRes (XQ)
2K (2048 x 1152) @ max 120p, ProRes (HQ)HD (1920 x 1080) @ max 120p, ProRes (HQ)2K (2048 x 1152) @ max 120p, ProRes
See complete Recording Modes & Times ...
