Sony FX30

Released : September 2022
Sensor : Super 35mm (23.3x15.5 mm)
Lens Mount : E
Base Sensitivity : 800 ISO & 2500 ISO
Weight : 562 g
Dimensions : 130 mm x 78 mm x 85 mm
COMPARE WITH CAMERA
chevron_right
chevron_right
COMPARE WITH CAMERA
chevron_right
chevron_right
Dynamic Range
Stops (SNR=2) Stops (SNR=1) Waveform IMATEST Patch Range Codec ISO Framerate Resolution Gamma Comment
11.4 12.6 14.6 XAVC S-I 4K 800 25 3840x2160 SGamut3.Cine/SLOG3
11.0 12.6 14.9 XAVC S-I 4K 2500 25 3840x2160 SGamut3.Cine/SLOG3
Rolling Shutter
Rolling Shutter Image Sensor Mode Codec Framerate Resolution Comment
15.9 ms Full Sensor XAVC S-I 4K 25 3840x2160
Recording Modes Overview
HD (1920 x 1080) @ max 240p, XAVC S HD HD (1920 x 1080) @ max 240p, XAVC S HD HD (1920 x 1080) @ max 240p, XAVC S HD
HD (1920 x 1080) @ max 200p, XAVC S HD HD (1920 x 1080) @ max 200p, XAVC S HD HD (1920 x 1080) @ max 200p, XAVC S HD
4K UHD (3840 x 2160) @ max 119.88p, XAVC HS 4K (H.265) HD (1920 x 1080) @ max 119.88p, XAVC S HD HD (1920 x 1080) @ max 119.88p, XAVC S HD
4K UHD (3840 x 2160) @ max 119.88p, XAVC HS 4K (H.265) 4K UHD (3840 x 2160) @ max 119.88p, XAVC S 4K HD (1920 x 1080) @ max 119.88p, XAVC S HD
