Blackmagic Design URSA Mini Pro 12K

Released: July 2020
Sensor: Super 35 mm (27.03 x 14.25 mm)
Lens Mount: PL, EF
Base Sensitivity: 800 ISO
Weight: 2600 g
Dimensions: 223 mm x 147 mm x 151 mm
COMPARE WITH CAMERA
chevron_right
chevron_right
Check Rec Modes & TimesCheck Lens Coverage
COMPARE WITH CAMERA
chevron_right
chevron_right
Advertisement
Advertisement
Advertisement
Dynamic Range
36th best - max. 11.8 (SNR=2)Check Ranking
44th best - max. 12.8 (SNR=1)Check Ranking
Stops (SNR=2)Stops (SNR=1)WaveformIMATESTPatch RangeCodecISOFramerateResolutionGammaComment
11.812.816.6BRAW8002512288x6480BMD Film
11.512.616.5BRAW800258192x4320BMD Film
11.312.516.6BRAW800254096x2160BMD Film
See Lab Test Article ...
Rolling Shutter
10th best - min. 7.8 msCheck Ranking
Rolling ShutterImageSensor ModeCodecFramerateResolutionComment
15.7 msSuper 35BRAW2512288x6480Full Sensor Area
7.8 msSuper 35BRAW258192x4320Full Sensor Area
7.8 msSuper 35BRAW254096x2160Full Sensor Area
See Lab Test Article ...
Recording Modes Overview
4K Super16 (4096 x 2160) @ max 239.76p, Blackmagic RAW 8:14K Super16 (4096 x 2160) @ max 239.76p, Blackmagic RAW 12:14K Super16 (4096 x 2160) @ max 239.76p, Blackmagic RAW 5:1
4K Super16 (4096 x 2160) @ max 239.76p, Blackmagic RAW 18:14K Super16 (4096 x 2160) @ max 200p, Blackmagic RAW 8:14K Super16 (4096 x 2160) @ max 200p, Blackmagic RAW 12:1
4K Super16 (4096 x 2160) @ max 200p, Blackmagic RAW 18:14K Super16 (4096 x 2160) @ max 200p, Blackmagic RAW 5:14K (4096 x 1704) @ max 160p, Blackmagic RAW 18:1
8K (8192 x 3408) @ max 160p, Blackmagic RAW 12:14K (4096 x 1704) @ max 160p, Blackmagic RAW 5:14K (4096 x 1704) @ max 160p, Blackmagic RAW 12:1
See complete Recording Modes & Times ...
