New batch of Kessler CineDrive systems on sale June 12 at 1 PM ET

New batch of Kessler CineDrive systems on sale June 12 at 1 PM ET

Tomorrow at 1pm ET, Kessler release their next batch of CineDrive systems.

CineDrive is Kessler’s latest line in motor controlled motion camera systems. It’s a digitally driven system, enabling integration between computers and smart devices (via a dedicated app).

Kessler’s previous flagship line was the Oracle, an analogue based system. The CineDrive system offers a much more user-friendly digital interface. It uses keyframes and bezier curves to depict programmed camera moves, which pose familiarities with post effects programs and non-linear editing platforms.

CineDrive interface

The system is essentially made up of 5 devices:

– Your camera support (slider, pan tilt head, follow focus)

– A motor for that specific camera support (Different strength motors are interchangeable depending on the whether you are shooting real time or time-lapse)

– A motor control module (made separate from the motor to ensure ease of change between motor strengths)

– A brain module (piece of hardware which collates all of the inputs from the control modules and provide one output to your end device)

– End device (computer, smart device etc.)

CineDrive 3 axis setupCineDrive supports what is almost an unlimited amount of axis control (up to 254).

Whilst 254 axes maybe a little excessive and financially un-achievable for most, it should encourage more use of motion controlled zoom and focus within shots.

Each motor control module is magnetic, and all can be linked to the brain through a daisy chain to ensure cables runs are kept to a minimum.

All motors utilise a precision worm drive system, which promises ultra smooth ‘lash-free’ motion.



The brain supports USB, Ethernet and SD connections. The latter for memory expansion and transfer of motion data from device to device.

It also supports wifi, which in the near future will provide wireless connectivity to wifi devices.

Whilst motion camera support is the pinnacle to high end cinematic time-lapse photography, the use of it for real time image acquisition shouldn’t be overlooked.
The feature of being able to repeat the exactly same move time and time again can play a big part within other industries such as visual effects.

The system is not cheap, and therefore not targeted at the budget film maker. A 3-axis setup without slider starts at $5999.95.

6
Leave a Reply

guest
Filter:
all
Sort by:
latest
Maciej Mazurek
Maciej Mazurek
Guest
June 12th, 2013

Thanks Tim!
I have send them an email as well :)

Maciej Mazurek
Maciej Mazurek
Guest
June 12th, 2013

Hi!
Do you know how much weight I can put on the motorized head? I want to put Sony F5 system which weights approx. 7kg on it…

Maciej Mazurek
Maciej Mazurek
Guest
June 12th, 2013
Reply to  Tim Fok

I just got the reply from the Kessler- recommended capacity of the head is 25lbs (approx. 11kg)

Maik Thomas
Guest
June 11th, 2013

“It also supports wifi, which in the near future will provide wireless connectivity to wifi devices.

it already does it :)

Guest
June 11th, 2013
Reply to  Maik Thomas

Good to know. Eric implies in the overview video that it wasn’t far behind.
