PowerGXND – World’s First Variable Graduated ND Filter on Kickstarter

January 24th, 2018 icon / message-square 2
PowerGXND - World's First Variable Graduated ND Filter on Kickstarter

Aurora PowerGXND is the world’s first hard-transition variable GND filter. Its crowdfunding campaign has already been successful, but there is still time to take part.

Power GXND, Source: Aurora Aperture

What are GND filters?

Gradual neutral-density (GND) filters are optical filters with a variable light transmission. They are mostly used for landscape photo and videography because they limit light transmission in the upper part of the shot in order to not overexpose sky. At the same time, they don’t affect light transmission in the lower part of the shot, and retain enough detail in the darker parts. They can either be soft edge or hard edge depending on the width of the gradient.

Aurora GXND – Variable GND Filter

Until now, only GND filters with fixed values were available. California-based company Aurora Aperture wants to change that with its new product – the Aurora GXND – which it claims is the world’s first variable GND filter.

It is a hard-transition (hard edge) variable GND filter with a continuously-variable range of up to 5 stops (ND 0 – 1.5). Aurora GXND is available in three different diameters  (105mm, 82mm and 62mm) and can be set up depending on the light conditions and type of scene to help avoid over- or underexposure.

Power GXND, Source: Aurora Aperture

Aurora Aperture started designing the filter in November 2016 and decided to launch the product through crowdfunding. The Kickstarter campaign was launched on 13th January 2018 and has already reached its funding goal. There are still more than two weeks until the campaign ends, so there is still some time to take part if interested. The company plans to ship the filters in may 2018.

They provide two mounting options for the filter:

1. Slim Adapter

The slim adapter allows single-axis movement and rotation of the filter to adjust where exactly in the frame you would like to place the transition. It can be locked in place by the built-in screw. There are three sizes available:

  • L – For ⌀105mm filter with lens filter thread size 82mm, free rotations on both filter and lens thread, and single axis movement movement between filter and lens, included lens adapter rings of 77, 72, 67, 62, and 58mm.
  • M – For ⌀82mm filter with lens filter thread size 62mm, free rotations on both filter and lens thread, and single axis movement movement between filter and lens, included lens adapter rings of 58, 55, 52, 49, and 46mm.
  • S – For ⌀62mm filter with lens filter thread size 49mm, free rotations on both filter and lens thread, and single axis movement movement between filter and lens, included lens adapter rings of 46, 43, 40.5, 39 and 37mm.

Power GXND Slim Adapter, Source: Aurora Aperture

2. Square Adapter Plate

The square adapter plate can be used to mount the round filter for use in a square filter system, while still making it possible to rotate the filter itself inside the adapter. The plates for inserting the circular filter are also available in three sizes:

  • L Plate – For using a ⌀105mm filter on a 130mm system (e.g. Cokin X-Pro)
  • M Plate – For using a ⌀82mm filter on a 100mm system (e.g. Cokin P)
  • S Plate – For using a ⌀62mm filter on a 75mm system (e.g. Lee Seven5)

For the square adapter plate, there is also a square mount system. It too is available in three sizes:

  • 130mm system compatible with Cokin X-Pro and 130mm (width) square filters, adapter rings of 82, 77, 72, 67, 62, and 58mm included.
  • 100mm system compatible with Cokin Z and other 100mm (width) square filters, adapter rings of 62, 58, 55, 52, 49, and 46mm included.
  • 75mm system compatible with LEE Seven5 and 75mm (width) square filters adapter rings of 49, 46, 43, 40.5, 39, and 37mm included.

Power GXND values examples, Source: Aurora Aperture

The filter features hard stops which enable users to find the exact value and not overshoot the functioning range of the ND filter. It sports Schott B 270® Ultra-White Glass and polarization film, with multi-layer nano coatings that make it capable of withstanding dusty and wet environments.

This is their campaign presentation video:

Although the funding goal has been reached, the company has a stretch goal of $100,000 which, if reached, will add free adapter rings for all three square systems it offers.

The filter itself will be out of focus in the final image, as will the transition, but it is still a very sharp edge which would only work well in certain situations, like totally flat horizons or straight edges. Soft transitions produce much more natural-looking results in most real-world situations. It is, however, not yet possible to manufacture a variable GND filter with a soft transition.

The prices for the filter systems in the Kickstarter campaign range from $126 to $340 depending on the filter size and mounting option. According to Aurora Aperture, these prices are about 33% cheaper than expected retail prices, with early bird prices being even up to 50% less.

Do you use GND filters? Would you consider buying a variable one? Let us know in the comments below.
